E.Q.R.S. In the event of an accident, in can be difficult as well as dangerous for a third party to try and remove the helmet from a rider. The NXR features Shoei's exclusive EmergencyQuickReleaseSystem. By pulling this EQRS ring tab, a third party can remove the helmets cheek pads and remove the helmet safely lowering the risk of further injury.
LinerThe NXR impact absorption liner consists of 2 liners in different hardness. In the event of impact the liner works in conjunction with the shell to absorb the energy of the impact whilst protecting the rider.
AIM Shell Organic fibre and multi-composite fibre in various layers for a shock-absorbent shell with optimum rigidity Advanced Integrated Matrix shell
Air intakes are placed in the centre of the forehead and both sides of the helmet for stable absorption of riding wind, this is especially effective in a sports riding position. Wind absorbed from the 3 intake holes goes directly to the inside liner giving real ventilation performance to the rider. Air outlets to improve performance are utilised to through 4 outlet holes inside to exhaust hot air effectively. An enhanced balance of air absorption and exhaustion achieves a high quality ventilation system, which cools all parts of the head evenly.
Visor system is newly developed for NXR with favoured injection moulded visor made of polycarbonate. Curvature and thickness of newly developed CWR-1 visor are varied part by part to improve optical performance and realise natural and clear vision with minimum distortion. Ribs on top and bottom improve rigidity of a visor itself and eliminate bending of a visor by wind pressure or during opening or closing. Down & Press Double Action, shown in drawing below, for visor opening and closing in variable axis realises close contact with window beading by power of spring which is stronger than that of former model. While fully closed, a visor contacts with window beading closely and tilting of a visor by wind pressure is blocked, and so, high air tightness is realised. Not only a visor but also a visor base is newly developed for NXR. Maintaining easy and firm fixing and removing of a visor, it allows fine tuning of visor setting easily by rotating a dial of a visor base. PINLOCK fog-free sheet in CWR-1 is standardised.
| Name | Shoei NXR - White |
|---|---|
| Short Description | - Reduced overall physical size |
